The Honda D15B Engine Manual. Throughout its production run, the Honda D15B has had eight different versions. With so many different applications, the D15B series of engines might be described as flexible. The D15B engines are part of Honda’s inline four-cylinder series, which includes the D12 and D17 engines. However, throughout this post, we will focus on the D15B engines and their common issues, dependability, and performance potential.

The Honda D15B engine is most typically linked with Civics manufactured between 1989 and 1995. However, there are numerous other applications for slightly lesser-known models, primarily in automobile markets other than the United States, including as Japan, Europe, and Australia. These D15Bs may be considered obsolete, but many older Honda engines are still favored by driving fans all over the world.

The Honda D15B engines are enjoyable projects for individuals who want to improve their power and performance or for drivers who need an engine switch due to the failure of their prior engine. They have easily applied modifications, accessible parts, simple maintenance, and above-average reliability. Older Civics with catastrophic engine failure frequently use the D15B for engine rebuilding or a complete engine replacement. The D15B V-TECs are well-known for their minimal weight and high durability. The Honda D15B, like most engines, has flaws. Let’s take a look at some of the specifications and applications of the Honda D15B engine, as well as some of its most typical faults and general dependability.

The Honda D15B Engine Manual

Honda D15B Specifications

The Honda D15B engine specifications are as follows:

The Honda D15B Engine Manual

The use of an aluminum block and head helps to reduce total weight for the Honda D15B, with the engine weighing 254 pounds. The SOHC VTEC valvetrain also contributes to the lightweight four-cylinder’s efficiency while increasing power. Although horsepower and torque aren’t particularly impressive on paper, the Honda D15B is remarkably efficient and durable for its size.

It’s worth noting that eight different variants of the DB15 engine have been used in over 30 different Honda vehicles. The majority of these applications are Civic variants found in Japan, the United Kingdom, Australia, and other automotive markets. However, there are also other applications that we will discuss below. The following section is a comprehensive list of all models that use the Honda DB15 engine.

What Vehicles Make Use of the D15B Engine?

The Honda D15B engine, as well as its derivatives, can be found in the following vehicles:

  • 1988 CRX 1.5X
  • Civic 25XXT Formula (Japan) 1990
  • Civic Ferio MX EG8 (Japan)
  • Capa GA4 (Japan) 1998-2001
  • Honda Civic SH4 EF1 1988-2001


  • Civic Vti (Japan) 1992-1995
  • CRX DelSol (Japan) 1992-1998


  • Civic Hatchback, 1988-1991


  • Civic GL/DX/LX/CX (CX Canada) 1988-1991
  • 1988-1991 Civic DX Wagon Wagovan
  • 1989-1991 CRX DX
  • Civic LSi Hatch/Saloon (Europe) 1992-1995
  • Civic DXi Hatch/Saloon (Europe) 1992-1995
  • Concerto (Europe) 1990-1995


  • Civic Shuttle GL, 1988-1995
  • Ballade 150-16 & 150 (South Africa) 1989-1996
  • Civic LX (New Zealand) 1992-1995
  • Civic LX/EX (New Zealand) 1988-1991
  • Civic EX (South Africa) 1992-1995


  • Civic GL (Australia) 1989-1993


  • 1992-1995 Civic


  • 1988-1991 Crx HF


  • Civic GLi (Australia) 1991-1995
  • 1992-1995 Civic DX/LX
  • Civic LSi Coupé (Europe) 1992-1995
  • Civic Del Sol S 1993-1995
  • City SX8 from 1998 to 2000

Engine Reliability of the D15B

These days, it’s difficult to find a Honda D15B engine with low mileage. This is owed not only to their antiquity, but also to their exceptional reliability and lifespan. Of course, each engine is subjective and has flaws. Some of these problems can be avoided with regular maintenance and fixes. However, it is extremely normal for D15Bs to travel up to 150,000 miles without requiring major or costly repairs. We enjoy the engine’s dependability, but it’s vital to remember that no engine is flawless. The most typically reported faults for the Honda D15s include damaged crankshaft pulleys, float engine revolutions (valve float), cracks in the exhaust manifold producing a diesel-like sound, and minor oil leaks.

Regardless of the concerns highlighted, we believe that this engine provides outstanding value in terms of dependability and longevity. Given that these engines can often last up to 150,000 miles with good maintenance, we consider the Honda D15B’s overall reliability to be above average. Of course, not every D15 is flawless, but these older Honda engines appear to hold up excellently under wear and abuse. With that said, let’s take a closer look at some of the more typical issues we highlighted below.

The Honda D15B Engine Manual

Honda D15B Engine Issues

Again, not every D15B engine will have these issues, especially if it has been regularly maintained. However, broken crankshaft pulleys and valve float appear to be common enough that we will discuss them more below. Cracks in the exhaust manifold can also occur with time, necessitating an expensive repair. These issues are far more common in Honda D15B engines that have been modified without the required supportive mods and in engines that have been driven vigorously. Regardless, this does not change our positive assessment of the Honda D15B engine’s dependability. This engine has withstood the test of time and continues to outlast many newer engines on the market today.

Crankshaft Pulleys Broken

The principal function of a crankshaft pulley is to power the drive belts that control the engine’s accessories. The water pump, alternator, a.c. compressor, and assisted steering pump are examples of engine accessories (or auxiliary elements). Minor signs of a broken crankshaft pulley include rough idle and intermittent engine vibrations. The harmonic balancer assembly is connected to the crankshaft pulley. A widespread misunderstanding is that these two names are synonymous, despite the fact that they are two completely independent components that function together.

If the crankshaft pulleys are not properly repaired, more serious problems, such as a failing transmission, may arise. Other potentially costly repairs include a faulty alternator and a faulty power steering pump. If a broken camshaft pulley is beyond repair, many experts recommend a total engine switch or considerable rebuild. If your D15B is having rough idle and acceleration hesitation, it is critical to inspect the crankshaft pulleys before severe engine damage occurs.

Problems with the Valvetrain/Valve Float

Valve float is caused by a loss of adequate valve spring pressure. When engine valves do not close properly, raw gasoline and inappropriate airflow might enter the exhaust or even back into the intake system. Problems with valve float, in particular, can cause power to drop at higher rpm. Severe valve float can cause significant loss of top-end power as well as sputtering sounds at higher rpm. This issue has the potential to destroy the D15B’s camshafts, pistons, and valvetrain system. As a result, it’s critical to address any valvetrain issues as soon as possible before they escalate into far more costly repairs or perhaps a new engine swap.

Cracks in the Exhaust Manifold

Cracks in the exhaust manifold may form over time as a result of exposure to various high temperatures. Constant temperature variations can cause the manifold to expand and compress sufficiently. Cracks can form as a result of this expansion and contraction. These cracks will continue to expand, allowing more air into the manifold itself. These exhaust manifold cracks, if left unrepaired, can cause significant engine damage such as overheated and fractured heads or even blown head gaskets.

For the Honda D15B, there are several indicators of broken manifolds. Visible cracks on the manifolds are obviously a dead giveaway. However, you may notice the manifolds emitting an unusual sound. That sound could be caused by exhaust gases leaking through the gasket and fractures. Exhaust manifold cracks can also cause a distinctive exhaust odor and a little loss in performance. Always fix any discovered exhaust manifold cracks as soon as possible before they evolve into far more problematic and costly engine repairs.

Related : The Subaru EJ207 Engine Reliability – Specs and Issues

D15B Upgrades and Modifications

The D15 engines are widely renowned for responding readily to changes. However, because this engine series has over 30 different applications, it’s critical to check appropriate fitment for any alterations under consideration. Regardless, we’ll go over some of the most typical modifications that Honda drivers make to their D15Bs.

Because of their low cost and ease of installation, many drivers seek out various introductory mods for their D15B engines. Because of the large market for older Honda vehicles, a new cold air intake is usually one of the first solutions. Following the installation of a new intake, drivers wanting improved performance noises and more airflow frequently update the exhaust system. We recommend a thermal exhaust for the Honda D15B since drivers have expressed a need for an exhaust shield to protect their vehicles from the extra heat produced by some exhaust systems. Upgraded valve trains and valve springs have also contributed significantly to the performance of the Honda D15B engines.

More expensive changes, such as upgraded intake manifolds and new cams, can increase the power and performance of your D15B while reducing oil leaks. Certain D15s have reported camshaft difficulties, increasing the worth of the potential upgrade. However, when raising power significantly, it is critical to optimize your engine. We frequently recommend a tune for any engine attempting to gain significant horsepower and torque. Without the necessary supporting mods and a good tune, you will most likely not see enough power gains, especially without sacrificing engine durability.

Summary of the Honda D15B Engine Guide

Overall, we think the Honda D15B engines are great in terms of pricing, longevity, and performance. With no substantial repairs reported before the 150,000-mile milestone, this engine demonstrates that it can withstand the test of time. Wear and tear can cause a variety of small faults throughout the D15 series. However, we discovered that the majority of these issues were caused by inadequate maintenance, late repairs, and harsh driving on custom projects without proper supportive upgrades. Of course, no engine is flawless, and the D15B has flaws, particularly as it approaches high mileage. Regardless, these engines are famous for their employment in many older Civics and other Honda cars.

The D15B’s dependability and longevity have earned it a place in the hearts of Honda enthusiasts to this day. Because of its low cost and easy availability of replacement components, the D15B is still used in many engine swap projects. Furthermore, these engines serve as good ambassadors for the JDM market and the several international regions where the D15s were produced. Most drivers associate the D15B with older Civics from 1980 to 1990. Nonetheless, with over 30 different versions and models utilizing this engine, the overall adaptability is obvious.

We studied and analyzed three of the most prevalent issues that many D15B drivers may encounter. First, broken crankshaft pulleys might disrupt your engine’s accessories, eventually leading to more serious engine difficulties. Second, due to wear and tear and exposure to various high temperatures, valvetrain difficulties and exhaust manifold cracks may develop over time. Regardless, major issues with D15 engines are documented less frequently than with other similarly sized engines of the time. Proper maintenance and prompt repair response can ensure that your D15B engine is a dependable everyday driver.

This engine is iconic for Honda, and we admire the D15B series for its significant impact on the automobile industry.
